集成電路測試開發、驗證、分析、試驗；集成電路圓片、成品批量測試；電路入廠檢測及篩選考核測試；測試系統租賃服務；探針卡制作服務；其他配套服務；
二極管、三極管、場效應管、光耦器件和整流橋等各類分立器件；各類線性電路、運放電路、比較器；LDO、功率穩壓器、電源電路； 鋰電池保護、控制電路；DC/DC、AC/DC、脈寬調制器電路；音頻電路；馬達驅動電路；二級管陣列、EMC濾波電路；模擬開關、 SIM卡控制器、多路轉換器電路；電阻類、電容類觸摸屏電路；數模混合電路等。
Model |
Name | Vender | item | Main Specification |
| UF200 | Prober | TSK(JAPAN) | Full Auto / 5" ~ 8" Wafer / Accuracy ±2μm | |
| P8 | Prober | TEL(JAPAN) | Full Auto / 5" ~ 8" Wafer / Accuracy±2.5μm | |
| V7100 | Tester | VTT(JAPAN) | 128 channels Digital I/O ,1M Depth,/ 10MHZ | |
| SINT700 | Tester | SINETEST(SINGAPORE) | FVI45 | Fully independent six channels floating and flexible V/I 45V/400mA16 Bit Force/Measure. |
| FVI1000 | Fully independent two channels floating V/I 1000V/10mA,16 Bit Force/Measure. | |||
| FPVI20 | Fully independent two channel floating and flexible V/I 20V/20A,16 Bit Force/Measure. | |||
| QTMU | Quad Timing Measure unit 3nS. | |||
| TR6850 | Tester | TRI（TAIWAN） | DVI | 2 channels, each channel with 48V/2A，16 Bit Force/Measure. |
| OVI | 8 channels, each channel with 20V/200mA, 16 Bit Force/Measure. | |||
| AC64 | 64 channels Digital I/O,4M Depth,33MHz. | |||
| TMU | Quad Timing Measure unit 10nS. | |||
| AWG | 4 Output Channels, 16 Bit1Mhz AWG and 16 Bits for 500K /14 Bits for 10Mhz digitizer. | |||
| TR6800 | Tester | TRI（TAIWAN） | PVC | 2 channels, each channel with 32V/1A，16 Bit Force/Measure. |
| OVI | 8 channels, each channel with 12V/300mA, 16 Bit Force/Measure. | |||
| TMU | Quad Timing Measure unit 10nS. | |||
| T862 | Tester | QATEST（China） | DVI3 | 2 channels, each channel with 40V/2A (20A pulsed)，13 Bit Force,16 BitMeasure. |
| OVI | 8 channels, each channel with 40/100 mA (500 mA pulsed), 16 Bit Force/Measure. | |||
| HVS | 1 channel floating V/I, each channel with 1500V/10mA(100V/100)mA，16 Bit Force/Measure. | |||
| TMU | Quad Timing Measure unit 10nS. | |||
| STS8200 | Tester | ACCOTEST（China） | FPVI10 | 2 channels floating V/I, each channel with 16 Bit 40V/10A pulsed |
| FOVI100 | 8 channels floating V/I, 4 channels per bank, each Channel with 16 Bit, 40V/100mA,1A pulsed. | |||
| HVI1K | 1 channel floating V/I, each channel with 1000V/10mA，16 Bit Force/Measure. | |||
| QVM | 4 channels floating 100V DC+AC Voltage Meter with 18 Bit 1MSPS and 12 Bit 10MSPS digitizer each channel. 64K x 18 Bit capture depth each channel. | |||
| DIO | 8 channels with 5Mhz, ‐2V‐+7V driver/compared. | |||
| ACSM+ | 4 Output Channels, 16 Bit 100KSPS AWG and 16 Bit 200KSPS digitizer. | |||
| TMU+ | Single, Dual, Quad channels Time Measurement Unit, <1ns resolution. |
